OB-HD-I-MC-TY/UPB

OB-HD-I-MC-TY/UPB

New Standard Pro Bottom Tool Holder
  • Clamping Type = Mechanical
  • Adaption = UPB-VI
  • Vertical Alignment (Ty)
  • Working height H = 130mm
  • Width W = 150mm
  • Max. load = 500ton/m

Description

New Standard Pro bottom tool holderUPB-VI, ,
Working height=130mm, Width=150mm, provided with UPB-hole pattern which is suitable for the fixing holes according to drawing no.: 0377026, mechanical clamping by means of set screws M10 pitch 100mm with centre 1000mm pitch 100mm, Tx-alignment, Ty-alignment (manually by means of single point adjustment), Material=C45 not hardened, max.load: 500ton/m.hardenend
Delivery without guards and mounting hardware.
