OB-II-HC/ES IV

OB-II-HC/ES IV

New Standard Premium Bottom Tool Holder
  • Clamping Type = Hydraulic
  • Adaption = tang
  • Pressure surfaces CNC-Deephardened ® (2-4mm / 56-60 HRC)
  • Working height H = 66mm
  • Width W = 87mm
  • Max. load = 300ton/m

Description

Custom Style New Standard Premium bottom tool holder,
Working height=66mm, Width=87mm, provided with Amada adaptation Width=60.00mm, hydraulic clamping (max. 50bar), oil supply ø10mm, left-end, Material=CR-MO, pressure and reference surfaces CNC-Deephardened® (2-4mm / 56-60HRc), weight: 32.5kg/m, max.load: 300ton/m.hardenend
Delivery without hydraulic power pack.
